Dynamo 600X

Product Highlights

• 10-inch inverted surround poly cone woofer
• 240 Watts (peak) amplifier
• Low-turbulence, ported design
• Digital control system via smartphone app
• Anthem Room Correction (ARC®) via smartphone app or PC
• RCA and speaker level inputs
• SWT-X Wireless Receiver & Transmitter (sold separately)

Specifications

Specifications are subject to change without notice

Frequency Response 27–200 Hz ±3 dB. Anechoic in LFE mode.

Impedance RCA: 8,300 Ohms

Speaker Level: 2,000 Ohms (red to black)

Low Frequency Transducer 10” (25.4cm) high-excursion, inverted surround, polypropylene cone in a stamped steel basket with extended throw driver assembly. Ported.

Amplifier 120 Watts (240 peak)

Software Sub Control App: iOS and Android

Anthem Room Correction: iOS, Android, and PC

Room Correction Anthem Room Correction (ARC)

Controls (Backplate) Level: Min–Max

Setting Control: Local, App

Power Mode: On, Auto

Controls (via Bluetooth) Level: -40 to 12dB

Low-Pass Filter (Frequency): 35–120Hz

Low-Pass Filter (Order): Bypass, Third, Fourth

Phase: 0–180° (1° Increments)

Phase (Polarity): Normal, Inverted

Preset Listening Modes: Music, Night, Movie

20–30Hz Level: ±10dB

Anthem Room Correction (ARCTM): On, Off Tone

Sweep (20–120Hz): On, Off, Pause (Frequency)

Inputs (Audio) Line Level: Left, Right/LFE

Speaker Level: Left and Right via banana jacks

Inputs (Audio, Wireless) SWT-X Receiver & Transmitter (sold separately)

Inputs (Other) USB: Micro USB (for ARC/Firmware Update)

Power Draw Typical: 30W, Max: 150W, Idle: 4W, Standby: 0.5W

Feet Rubber

Weight 35.5 lbs. (16.1 kg)

Dimensions 16.3" x 14.5 " x 14.9 "

(41.5 cm x 36.7cm x 37.8 cm)

Finish Satin Black
