Affordable High-Performance Solutions

The Installer Series™ by MartinLogan is a line of affordable high-performance products, featuring custom installation solutions for in-wall, in-ceiling, and outdoor applications. Manufactured to the highest standards of quality, these products are available through authorized specialty custom installation specialists and carry the full MartinLogan warranty.

Specifications

Specifications are subject to change without notice

Frequency Response 70–20,000 Hz ±3dB

Aiming Rotate speaker assembly

Recommended Amplifier Power 20—80 watts per channel

Sensitivity 89 dB/2.83 volts/meter

Impedance 8 Ohms per channel/connection. Compatible with 4, 6 or 8 ohm rated amplifiers. Compatible with 4, 6, or 8 Ohm rated amplifiers.

Crossover Frequency 3000 Hz

High Frequency Transducer Two 3/4” (1.9cm) titanium domes

Low Frequency Transducer Dual voice-coil 6.5” (16.5cm) mineral-filled poly cone

Inputs Spring clip accommodates wire up to 12AWG

Weight 3.5 lbs. (1.6 kg)

Cut-Out Dimensions 7.75" dia.

(19.6 cm dia.)

Projection From Wall Surface 0.2" (0.5cm)

Depth Behind Wall Surface 3.4" (8.5 cm)
